Company of Proprietors of the Grand Junction Canal
>
Plans of the Grand Junction Canal
>
Plans of canal and branches
BW99/12/2/1
Plan showing section of the Grand Junction Canal from Toplock No. 90 to lock No. 97 from Crowley to Brentford
Showing land adjacent to canal including Hanwell Asylum, and showing Brentford Branch of GWR; shows flight of locks 93 to 97 close to each other; with reference giving details of area of land and with pencil note of surface water discharge at Warren Farm Playing Fields.
[mid-late 19th century]
BW99/12/2/1
1 sheet
