D1239.02

Boat Building Drawing. Bridgewater Canal Barge

Description

Timber details in plan, elevation and sections.

Reference code

D1239.02

Extent & medium

80mm x 600mm
3/8" = 1ft
Dyline print

image D1239

Comments
