Company of Proprietors of the Ellesmere Canal
>
Series of architectural drawings of Locks by William Jessop
BW95/3/2
"Plans of the lower gate cill for the narrow Locks for Ellesmere Canal"
Description
Plan and section; some measurements given. Endorsed "Locks and Gates - Ellesmere C". William Jessop, engineer.
Date
c1794
Reference code
BW95/3/2
Extent & medium
1sheet
![](static/img/col_canalrivertrust/tlcorner_frame.png)
![](static/img/col_canalrivertrust/trcorner_frame.png)
![](static/img/col_canalrivertrust/blcorner_frame.png)
![](static/img/col_canalrivertrust/brcorner_frame.png)
![bw95_3_2 image bw95_3_2](https://collections.canalrivertrust.org.uk/assets/object_images/7/03/55307/v0_web.jpg?_m=1474639696)
