Company of Proprietors of the Ellesmere Canal
>
Series of architectural drawings of Locks by William Jessop
BW95/3/1
"[Architectural drawing of] Gates of the narrow Locks for the Ellesmere Canal (for locks of 9 feet rise)"
Description
Two elevations; some measurements given. William Jessop, engineer.
Date
c1794
Reference code
BW95/3/1
Extent & medium
1 sheet
