Company of Proprietors of the Birmingham Canal Navigations
>
Water supply, sewers and drainage
>
Feeders
BW165/28/3/2
"Longitudinal and Transverse Sections of Proposed Feeder, from the Summit of the Old Birmingham Canal at Smethwick to Rotton Park Valley"
Description
Landmarks, reservoir and positions of cross sections marked on longitudinal section. Note "The New reservoir". Signed "[4th Jany London] Thos. Te[lford]". Endorsed "Smethwick Feeder (Telford)".
Date
[1820s]
Reference code
BW165/28/3/2
Extent & medium
1 sheet
