BW147/6
"Dudley Canal Extension from Netherton to Selly-Oak Section of Lapal Tunnel"
Description
Longitudinal section of part of the west end of Lapal Tunnel. Elevation not shown on document-right hand portion is missing.
Date
[early-mid 19th century]
Reference code
BW147/6
Extent & medium
1 sheet
