D1181

Boat building drawing. Docks & Inland Waterways Executive NE Division. Selby Boat 'Hillrake'. General Arrangement.

Description

General arrangement drawing showing plan and elevation

Reference code

D1181

Extent & medium

730mm x 530mm
1/2" = 1ft
Original Ink on tracing

image D1181
