D0890

River Weaver Navigation concrete and piling protection to river bank below Hunts Graving Dock

Description

Shows concrete anchors and tie rods to support piles.

Date

3/1/1910

Reference code

D0890

Extent & medium

730mm x 410mm
Paper
1/4" = 1ft

image d890

Comments
