D0865.20
River Weaver Navigation plan for one and a half (11/2) ton electric crane arrangement and detail and luffing gear
Stothert & Pritt Ltd, Engineers. Details of Luffing Gear. Drg No. 85924
29/11/1935
D0865.20
1010mm x 680mm
Paper
1", 1½", 3" = 1ft
Paper
1", 1½", 3" = 1ft
