D0865.04

River Weaver Navigation plan for one and a half (11/2) ton electric crane general arrangement

Description

Stothert & Pitt Ltd, Enginners, Bath. Screw jacks and travel motor house. Drg No. 98706

Date

3/1/1936

Reference code

D0865.04

Extent & medium

730mm x 550mm
Paper
1 1/2" & 3" = 1ft

image d865-4

Comments
