Home  / D0865.01

D0865.01

River Weaver Navigation plan for one and a half (11/2) ton electric crane general arrangement 1936

Description

Stothert & Pitt Ltd. Engineers, Bath. Drg No 98892. General Arrangement

Date

31/1/1936

Reference code

D0865.01

Extent & medium

990mm x 630mm
Paper
1/4" = 1ft
image D865-1
