D0844.03

River Weaver Navigation Northwich swing bridges cover plates for new cross girders

Description

Flange and web joint details. Drg No. 1817

Date

1/9/1926

Reference code

D0844.03

Extent & medium

290mm x 370mm
1" = 1ft
Blue Print

image d844-3

Comments
