D0470.08

Manchester Ship Canal Manhole details

Description

Manchester Ship Canal Company unitendified drawing no date very delicate. Showns possible manhole construction 6ft diameter connecting 2 3ft pipes.

Reference code

D0470.08

Extent & medium

680mm x 590mm
Ink on Paper and colour washed
1" = 1ft

image d0470-08
