D7902.13

MSC Pelican As Fitted Piping Arrangement

Description

boat building drawing/ plan 'MSC Pelican'/ Isaac Pimblott/ drawing no 759.16A yard no 759/ as fitted piping arrangement

Date

20/6/1956

Reference code

D7902.13

Extent & medium

790mm x 1080mm
3/4" = 1ft
Print
image d7902-13
