D5295.32

Ralph Brocklebank Saloons and Panelling Drawing

Description

Boat Building Drawing/ Daniel Adamson Sections and elevations and plans showing the panelling in the saloon, overlayed in red with the lighting electrical layout.

Reference code

D5295.32

Extent & medium

1/2" = 1ft
950mm x 650mm
Paper
image d5295-32
