D5295.04
Tug Ralph Brocklebank, Proposed Re-arrangement of Passenger Accommodation, Bridge Deck
Description
boat building drawing/ Daniel Adamson
Proposed changes to the bridge deck accommodation, increasing from 12 seats to 27 seats and extending the size of the deck.
Reference code
D5295.04
Extent & medium
680x400mm
tracing mono
tracing mono
