D2749.02

Mersey Flat 'Bedale' Sheet 2

Description

Boat Building Drawing. Deck view and fittings, deck view in frame.

Date

1972

Reference code

D2749.02

Extent & medium

115mm x 720mm
1/2" = 1ft & 1" = 1ft
Paper Print

image d2749-02
