D2749.01

Mersey Flat 'Bedale'.Sheet 1

Description

Boat Building Drawing. Lines, body plan, profile, profile in frame.

Date

1972

Reference code

D2749.01

Extent & medium

1150mm x 710mm
1/2" = 1ft & 1" = 1ft
Paper Print

image d2749-01

Comments
