D2740

Wooden Canal Boat to carry 25 tons

Description

Boat Building Drawing. General Arrangement plan and sections.

Reference code

D2740

Extent & medium

1070mm x 620mm
1/2" = 1ft & 1" = 1ft
Print on linen

image d2740
