D1446.02

Detail of hopper doors for S.No. 685 Hopper Barge

Description

Boat Building Drawing. Plans and elevations of 6 hopper doors.

Date

1948

Reference code

D1446.02

Extent & medium

980mm x 630mm
1" = 1ft & 3" = 1ft
Blue Print

image d1446-02
