D1408

River Weaver Navigation new ladder for dredger

Description

Plan Section and Elevation for No. 2 dredger.

Date

11/9/1909

Reference code

D1408

Extent & medium

920mm x 590mm
Couloured on paper
3/4" = 1ft and 3" = 1ft

image d1408
