Home / D1347

>

D1347

River Weaver Navigation land casting for the new Acton bridge

Description

Plan and sections of 90 degree curverd rail. Bridge shown in blue and casting shown in black and coloured.

Date

1900-1908

Reference code

D1347

Extent & medium

770mm x 720mm
Tracing Paper

image d1347

Comments
