D1296

British Waterways Board Marple aqueduct areas of reconstruction

Description

Drawing 48/6/1, showing plans and elevations of maintenance to brickwork on arches.

Reference code

D1296

Extent & medium

850mm x 760mm
Paper Print
1"=16ft 1/2"=1ft 1"=1ft

image d1296
