D1271.02

River Weaver Navigation. FG Stoney Patent.

Description

Details of lifting gear, Cylindrical Sluice drawn as 3D shaded image.

Date

3/1/1922

Reference code

D1271.02

Extent & medium

790mm x 620mm
1:1 3" = 1ft
Paper Print

image d1271-2

Comments
