D1239

Boat Building Drawing. Bridgewater Canal Barge

Description

Timber details in plan, elevation and sections. Poor quality Original See D1239.02

Reference code

D1239

Extent & medium

80mm x 600mm
3/8" = 1ft
Original pencil on tracing

image D1239-02
