D1399

Weaver Navigation - plan proposed hauling path at Cheshire Amalgamated Works 1908

Description

Elevation and section of proposed timber structure. Possible copy of original with bolt positions shown in ink.

Date

6/7/1908

Reference code

D1399

Extent & medium

Paper
1/2" = 1ft
450mm x 300mm

image d1399

Comments
