D1394

Weaver Navigation - Acton Bridge - plan of proposed Pier at the Weaver Refining Company - colour wash 1906

Description

Palns and elevations of timber structure of proposed Acton Bridge, showing timber piles and decking.

Date

6/10/1908

Reference code

D1394

Extent & medium

Colour Wash
1" = 4ft
430mm x 330mm

image d1394

Comments
