D0855

Weaver Navigation plan showing proposed timber bridges for towpath above and below new locks at Hartford and Newbridge 1875

Description

Elevation, Plan and Cross Section. Drawing No. IX

Date

10/1875

Reference code

D0855

Extent & medium

Paper
1/4" = 1ft 1" = 8ft
1020mm x 620mm

image d855

Comments
