D0843

Weaver Navigation - plan of coaling stage for steamers at Wallerscote Brunner Mond Co 1926

Description

Drawing No 41763 showing plan and section through coaling stage. Position of SS Crescent show as example.

Date

12/5/1926

Reference code

D0843

Extent & medium

1020mm x 680mm
24ft = 1" and 1/4" = 1ft
Blue Print

image d843

Comments
